Spindle taper: NT50
Distance between spindle nose and table surface: 30-510mm
Distance between spindle axis and column guideway: 370mm
Spindle speed range: 50-1500r/min
Swivel angle of vertical milling head: ±45°
Stroke of spindle quill: 50mm
Table size: 1600x360mm
Table travel (X, Y, Z): 1000x380x450mm/min
Table feed (X, Y, Z): 10-1500/10-1500/10-750mm/min
Table rapid speed (X, Y, Z): 1500/1500/750mm/min
T-slot: 3/18/80mm
Main motor power: 7.5Kw
Torque of X/Y/Z axis AC servo motor: 15N.m
Overall size: 2250x2150x2450mm
Net weight: 2600kg
