Table size(WxL): 305x1020mm
Max.longitudinal travel: 1130mm
Cross travel: 340mm
Max.distance from spindle center to table: 580mm
Magnetic chuck size: 300x1000mm
Speed of table longitudinal movement: 7-23m/min
Table transerve movement/ Auto feed: 0.1-8mm/min
Table transerve movement/ Repid speed: 990mm/min
Table transerve movement/ Feed of handlwheel: 0.02mm/div.
Wheelhand vertical movement/ Auto feed: -(H/R mode)0.005/0.01/0.02/0.03/0.04/0.05(only for D model)mm/stroke
Wheelhand vertical movement/Rapid speed: -(H mode)610mm/min(only for R model)480mm/min(only for D model)
Wheelhand vertical movement/ Feed of handlwheel: 0.005mm/div.
Grinding wheel Speed 50HZ: 1450rmp
Grinding wheel Speed 60HZ: 1750rmp
Grinding wheel (ODxWxID) Size:350x40x127mm
Spindle motor: 4/5.5kw
Hydranlic Motor: 2.2kw
Cooling pump motor: 0.09kw
Elevating motor: -(Hmode)0.25kW(Rmode)0.5kW(D mode servo motor)
Cross feed Motor: 0.04kw
Max.loading capacity of table(include magnetic chuck): 400kg
Total rated Power: 7.5/9kw
Height of machine: 1890mm
Floor space: 4400x2200mm
Gross weight: 3200kg
Packing dimensions(LxWxH): 2960x2210x2220mm
