Max workpiece to be ground: 1000x400mm
Max. table longitudinal movement: 1100mm
Distance from table to wheel spindle center: 570mm
Max. lateral displacement of the grinding head: 450mm
Grinding head vertical feed per revolution: 1mm
Grinding head vertical feed per grid: 0.01mm
Fast lifting motor
Power: 0.37kw
Speed: 1440rpm
Wheel Size(dia×width×bore): 350x40x127mm
Spindle speed: 1440rpm
Spindle motor: 7.5kw
The mechanical surface of the base of parallelis: 300/0.004mm
Surface roughness: Ra:0.63μm
N.W/G.W: 4000/4600kgs
Packing size: 2800x1750x2350mm
