Max. swing over bed: Φ400mm
Max. swing in gap: Φ630mm
Max. swing over slide: Φ220mm
Max. workpiece length: 750/1000/1500/2000/3000mm
Spindle bore: Φ52mm
Type of spindle:ISO 702/III NO.6 bayonet lock
Spindle speed: 24 steps 9-1600rpm
Spindle motor: 7.5kw
Diameter of quill: Φ75mm
Max. travel of quill: 150mm
Taper of quill: MT5
Tool O.D. size: 25×25mm
Max. X travel: 145mm
Max. Z travel: 320mm
X feed range: 93 kinds 0.028-6.43mm/r
Z feed range: 93 kinds 0.012-2.73mm/r
Metric threads: 48 kinds 0.5-224mm
Inch threads: 48 kinds 72-1/4t.p.i
Cooling pump: 60w
Length: 2382/2632/3132/3632/4632mm
Width: 975mm
Height: 1230mm
