Measurement range: 0 – 1% (could be customized)
Accuracy: ± 0.02 (typical)
Resolution: 0.001%
Temperature: -40°C to 120°C
Accuracy: 0.3°C (typical), 0.5°C (max)
Resolution: 0.1°C
Other Parameters:
Output: 2 channels 4 - 20mA analog output + RS485 digital output
Work power: DC 9V - 28V
Work current: <6 mA + load current
Work pressure: <100bar
Work temperature: -40°C - 85°C
Oil temperature: -40°C - 120°C
Mechanical connector: G1/2” BSP
Electric connector: M8 * 1, 6pin
Cable: 6pin, 2 meters, UL20866 6*22AWG
EMC standard: EN 61000-6-4:2007 & EN 61000-6-2:2005
Housing: 316 stainless steel
IP rating: IP66
Weight: 250g
