Applications: Measurement of EMF radiation in: industry, telecommunications, powerline, defense, medical
Sensor type: Isotropic, true RMS
Frequency band: GSM, UMTS, LTE
Measurement range: 0.04 -65 V/m (RMS)
Dynamic range: > 64 dB
Sensitivity: 0.04 V/m
Resolution: 0.07 dB
Interband attenuation: > 30 dB (1100 MHz) ; > 5 dB (2300 MHz)
Linearity: < ± 0.4 dB (0.2 - 50 V/m)
Isotropic deviation: < ± 1.7 dB
Temperature response: ± 0.6 dB (- 20 ºC to 60 ºC)
Operational mode: Online/Offline (Data download via USB)
Communication with Control Centre: GPRS (online mode)
Memory: Micro SD + Eeprom (1 Gbyte > 1 year)
Sampling frequency: Every 500 ms
Power supply: 12 Volt DC – AC/DC transformer included
Operating temperature: - 30 ºC to + 80 ºC with temperature recording
Environmental protection: IP 66
Installation: Wall, mast or flat surface. Can be installed on other equipment (traffic lights)
Dimensions: 157 mm x 178 mm x 133 mm
Control centre:
Allows automatic creation of reports on EMF levels.
Administration web page for remote system management.
Public web page to display measurements on any computer with Internet connection.
Multilingual interface.
Programmable system alarms.
Probe included: selective broadband measuring at GSM, 3G, LTE
Internal 3G/GPRS included · AC powered
