- Base Accuracy :
±0.2%F.S (5 to 100%F.S)(25ºC±2ºC)
±1.0%F.S (0 to 5%F.S)(25ºC±2ºC)
- Power supply variation : ±0.06 %F.S (±0.5% to the input of 0 to 5%)
- Load resistance variation : ±0.06 %F.S
- Frequency variation : ±0.2 %F.S (Based on 60Hz)
- Temperature characteristic : ±0.02 %F.S/ºC
- Response time : Less than 700msec (0→90%)
- Front adjustments : ±5% for zero and span
- Insulation resistance : Between input and output/power supply ; More than 100MΩ at 500 VDC
- Dielectric strength : Between input and output/power supply ; For 1 min. at 1500VAC
- Power supply voltage : 24VDC ±10 %
- Consuming current : Less than 30mA (At current output 24VDC); Less than 50mA (At voltage output 24VDC)
- Operating ambient temperature : -5 to 50ºC
- Operating ambient humidity : Less than 90 %RH (No-condensing)
- Storage temperature : -10 to 70ºC
- Storage humidity : Less than 60%RH (No-condensing)
- Case material : ABS resin (Black) 94V-2
- Weight : Approx. 80g
