Width: 4.7 mm
Height: 15.49 mm
Length: 10.41 mm
Fall Time: 11 ns
Rise Time: 16 ns
Technology: Si
Unit Weight: 2 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: Through Hole
Qg - Gate Charge: 15 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 156 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 13 ns
Typical Turn-Off Delay Time: 17 ns
Id - Continuous Drain Current: 8.7 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 850 mOhms
Vds - Drain-Source Breakdown Voltage: 500 V
Vgs th - Gate-Source Threshold Voltage: 5 V
