Technology: Si
Unit Weight: 200 g
Circuit Type: Thyristors / Thyristors
Current Rating: 140 A
Mounting Style: Screw Mount
On-State Voltage: 1.55 V
Holding Current Ih Max: 200 mA
Breakover Current IBO Max: 4.712 kA
Gate Trigger Current - Igt: 150 mA
Gate Trigger Voltage - Vgt: 2.5 V
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
On-State RMS Current - It RMS: 310 A
Non Repetitive On-State Current: 4.5 kA
Off-State Leakage Current @ VDRM IDRM: 50 mA
Rated Repetitive Off-State Voltage VDRM: 800 V
