Fall Time: 14.5 ns
Rise Time: 11.5 ns
Technology: SiC
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 20.3 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 56 W
Vgs - Gate-Source Voltage: - 10 V, + 22 V
Typical Turn-On Delay Time: 8.5 ns
Typical Turn-Off Delay Time: 8.5 ns
Id - Continuous Drain Current: 10.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 313 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 3.1 V
