Width: 5 mm
Height: 6 mm
Length: 4.5 mm
Fall Time: 100 ns
Rise Time: 100 ns
Unit Weight: 1 g
Dark Current: 2 nA
Photocurrent: 80 uA
Responsivity: 0.6 A/W
Mounting Style: Through Hole
Peak Wavelength: 950 nm
If - Forward Current: 50 mA
Vf - Forward Voltage: 1 V
Vr - Reverse Voltage: 60 V
Pd - Power Dissipation: 215 mW
Half Intensity Angle Degrees: 60 deg
Noise Equivalent Power - NEP: 4E-14 W/sqrt Hz
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
