Width: 5.18 mm
Height: 3 mm
Length: 5.49 mm
Core Type: Molded
Shielding: Shielded
Tolerance: 20 %
Inductance: 6.8 uH
Termination: Standard
Unit Weight: 200 mg
Core Material: Composite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 3.2 A
Saturation Current: 2.2 A
Maximum DC Resistance: 111 mOhms
Self Resonant Frequency: 750 kHz
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
