DC Voltage
200mV/2V/20V/200V ±(0.1%+5)
1000V ±(0.2%+5)
AC Voltage
200mV ±(1.0%+25)
2V/20V/200V ±(0.8%+25)
750V ±(1.2%+50)
DC Current
200uA/2000uA/20mA ±(0.5%+4)
200mA ±(0.8%+6)
20A ±(2.0%+15)
AC Current
20mA ±(1.5%+15)
200mA ±(1.5%+15)
20A ±(2.5%+35)
Resistance
200Ω ±(0.4%+10)
2kΩ/20kΩ/200kΩ ±(0.4%+5)
2MΩ ±(1.2%+25)
20MΩ/200MΩ ±(5.0%+45)
Conductance: (0.1~100)nS ±(1.0%+30)
Capacitance: 20nF/200nF/2uF/20uF/200uF/2mF ±(4.0%+50)
Frequency: 200Hz/2kHz/20kHz/200kHz/2MHz ±(0.1%+3)
Special Function
Diode √
Transistor test √
Continuity buzzer √
Low battery indication √
Data Hold √
Auto power off √
Backlight √
Function protection √
Shockproof protection √
True RMS √
Input impedance: 10МΩ
Sampling rate: 3 times/s
AC Frequency response: 40~1000Hz
Operation way: Manual range
Max. Display: 19999
LCD size: 70×50mm
Battery : 1.5V AAA LR03 Battery
