Output Voltage (0–Umax): 0–15V
Output Current (0–Imax): 0–20A
Output Power (0–Pmax): 0–300W
Operating Conditions:
Item: Specification
Rated input voltage: AC 220 V ±10%, 50 Hz (optional AC 110 V ±10%, 60 Hz)
Operating temperature: 0–40°C
Operating relative humidity: ≤80% RH
Storage temperature: −20–60°C
Storage relative humidity: ≤80% RH
Calibration ambient temperature: 23°C ±5°C
Voltage:
Setting resolution: <100 V: 10 mV; ≥100 V: 0.1 V
Setting accuracy: ≤0.1% + 5 digits
Readback resolution: <100 V: 10 mV; ≥100 V: 0.1 V
Readback accuracy: ≤0.1% + 5 digits
Temperature coefficient: ≤0.02% + 3 mV
Ripple & noise: ≤10 mVrms
Current :
Setting resolution : <10 A: 1 mA; ≥10 A: 10 mA
Setting accuracy : ≤0.2% + 10 digits
Readback resolution : ≤10 A: 1 mA; ≥10 A: 10 mA
Readback accuracy : ≤0.2% + 10 digits
Temperature coefficient : ≤0.02% + 3 mA
Ripple & noise : ≤10 mArms
Other Parameters :
Load regulation : <10 A: ≤0.1% Umax + 5 mV; ≥10 A: ≤0.2% Umax + 5 mV
Max output voltage : 15.5 V
Max output current : 20.1 A
Cooling method : Fan cooling
Weight : Approx. 2.0 kg
Dimensions : 230 × 80 × 150 mm
