DC voltage
Range: 200mV/2V/20V/200V/1000V
Basic accuracy: ±(0.05%+10)
AC voltage
Range: 200mV/2V/20V/200V/1000V
Basic accuracy: ±(0.5%+40)
DC current
Range: 200uA/2000uA/20mA/200mA/2A/10A
Basic accuracy: ±(0.2%+10)
AC current
Range: 200uA/2000uA/20mA/200mA/2A/10A
Basic accuracy: ±(0.8%+30)
Resistance
Range: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/60MΩ
Basic accuracy: ±(0.2%+5)
Capacitance
Range: 10nF/100nF/1000nF/10uF/100uF/1000uF/10mF/100mF
Basic accuracy: ±(5%+5)
Frequency
Range: 10Hz～10MHz
Basic accuracy: ±(0.02%+4)
Thermocouple
Range:
K indexing:-200.0°C～1372.0°C
Basic accuracy: ±(0.5%+3°C)
RTD
Range: Pt100:-200.0°C～800.0°C
Basic accuracy: ±(0.5%+3°C)
Display words: 22000
The measurement rate: 3 times / sec
Analog Bar graph: 20 times / sec
