Tested line diameter: Ф168mm Conductor or cable, or 168mm×245mm bus bar
Measurement range
Current: AC 0～6000A
Frequency: 45Hz～75Hz
Resolution:10mA；0.1Hz
Current precision (23℃±5℃,below 80%RH)
0.00A～99.9A: ±2%±5dgt
6.00kA～20.0kA: ±4%±5dgt
Frequency precision: ±1Hz
Gear shift: Automatic gear shifting
Size of insulation rod: About 5m long after extended; about 1m long after drawn back (5 nodes)
Data storage: 9999 sets
Sample frequency: 2 times/s
Instrument size :
Hook instrument: length width thickness 310mm×270mm×52mm
Receiver: length width thickness 250mm×100mm×40mm
Line voltage: Test bare conductor under 35kV, cable with safe insulation sheath under 110kV (operate with insulation rod)
Data maintenance: Press HOLD button under testing mode to maintain the data, and then press HOLD button again to cancel the maintenance
