Direct access to our certified experts
DC Voltage: 200mV/2V/20V/200V/1000V ±(0.1%+5)
AC Voltage: 2V/20V/200V/750V ±(0.8%+25)
DC Current: 200uA/2mA/20mA/200mA /20A ±(0.8%+5)
AC Current: 2mA/20mA/200mA /20A ±(1.5%+25)
Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20 MΩ/200MΩ ±(0.5%+8)
Capacitance: 20nF/200nF/2uF/20uF/200uF/2000uF ±(4.0%+10)
Frequency: 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz ±(3.0%+150)
Celsius:
(-20 ~ 1000)℃ (0-1832)℉ <400℃±(1.0%+40) / ≥400℃±(1.5%+150)
Special Function
Diode test √
Continuity buzzer √
Low battery indication √
Backlight √
Auto power off √
Function protection √
Restorable Fuse protection √
Shock proof protection √
Input impedance: 10MΩ
Sampling rate: 3 times/s
AC frequency response: (40-400)Hz
Operation way: Manual range
Max. Display: 19999
LCD size: 65×45mm
Battery: 9V (6F22)
General Characters
Product Net Weight Approx. : 400g(including battery )
Product Dimension 189×97×35mm
Standard Accessories Test leads / battery /instruction manual/TPO1 temperature probe/Testing accessories
