Source
DC current (DCmA)
Range: 0.000～22.000mA
Accurac ±(% of the set value +% of range): 0.01+0.015%
Resolution: 1uA
Analog transmitter (SIMULATE)
Range: 0.000～22.000mA
Accuracy
±(% of the set value +% of range): 0.01+0.015%
Resolution: 1uA
External power supply: 5 ～ 28V
Measurement
DC voltage (DCV):
Range: -2.000～28.000V
Accuracy±( % of Reading+ % of Range): 0.01%+0.01%
Resolution: 1mV
DC current(DCmA)
Range: -4.000～33.000mA
Accuracy ±( % of Reading+ % of Range): 0.01%+0.01%
Resolution: 1uA
Loop power supply(LOOP)
Range: 24V
The maximum current: 22mA
Driving ability:
No HART resistance of 1KΩ.
HART resistance is 750 Ω.
Power supply : four 1.5V alkaline batteries(LR6)
Battery life : about 360mA /5V under the condition of 20mA with 1kΩ load
Max. permitted voltage : 30V(between any two terminals or between any terminal and earth ground)
Operating temperature : 0°C～50°C
Operating relative humidity : ≤ 80%RH
Storage temperature : ≤ - 20°C～60°C
Relative humidity for storage : ≤ 90%RH
Temperature co-efficiency : 0.1×Basic accuracy/ ℃(Temperature<18℃ or >28℃)
Protection level : IP65(Dust,Water spray)
Display: 3.2 inch TFT color display
Size: 206(L)×97(W)×60(D)mm
Weight : 600g
Safety : EN61010-1:2001
