Resolving power: 320x240
Working band: 8~14um
Frame rate: 9Hz
NETD: 70mK at 25℃
Field of view angle: Horizontal 344, vertical 25.8
Lens: 6.5mm
Measuring range: Check temperature -10℃~45℃
Temperature measurement accuracy: 2℃ or ±2%
Temperature measurement: Supports temperature measurement of the highest point, lowest point, and center point in the entire screen, as well as temperature measurement in the area
Color palette: Enhance iron red, white heat, black heat, iron red, rainbow, red heat, cold blue, etc
Resolving power: 640x480
Frame rate: 25Hz
LED fill light: √
Screen size: 3.5 inches
Image mode: Edge fusion, overlay fusion, picture in picture, single infrared, single visible light
Language: Supports Simplified Chinese, Traditional Chinese, English, French, Spanish, Russian, Arabic, Japanese, and Korean
Working hours: 5000mAH high capacity battery, can be used for approximately 4 hours at 25 ℃ environment
Charging: Built in battery, recommended to use a 2A or higher universal USB charger
WiFi: Supports data transfer for Android App and PC software
Working temperature: -20C~+60°C
Storage temperature: -40C~+85C
Waterproof and dustproof: IP54
Product size: 230mm x 100mm x 90m
Capacity: Built in memory, approximately 6.6GB usable, capable of storing over 20000 images
Image storage mode: Three photo storage (infrared thermal imaging, visible light, and working state photos)
File format: TIFF format, supporting full range temperature analysis in the background
Data and charging interface: USB Type-C (supports charging and data transfer)
Analysis software: Computer analysis system can analyze and capture images
The mobile analysis system can analyze and capture images (currently only supports Android systems)
