Width: 185.4 mm (7.299 in)
Height: 34.8 mm (1.37 in)
Length: 234.8 mm (9.244 in)
Industry: Industrial
Approvals: CE, CSA, EN, cTUVus, cURus, FCC, IEC60950-1, UL60950-1
Compliance: CE, CSA, EN, cTUVus, cURus, FCC, IEC 60950-1, UL 60950-1
Efficiency: 80 % to 90 %
Output Power: 50 W, 200 W, 200 W
Input Voltage: 90 VAC to 132 VAC, 180 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4.242 kVDC
Number of Outputs: 3 Output
Open Frame/Enclosed: Enclosed
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 24 VDC
Output Voltage-Channel 3: 24 VDC
Operating Temperature Range: 0 C to + 85 C
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: 0 C
