Rated sine/random force (KN): 160
Shock force (KN):320
Frequency range
- Bare table (Hz): 1-2200
- Horizontal table (Hz): depends on the size of slip table
Max acceleration
- Bare table: 100G
- Horizontal table (G): depends on the mass of slip table
Max. Velocity (m/sec): 2
Max. Displacement (p-p) (mm): 51
Moving element mass (kg): 140
Maximum payload: 1600kg
Vertical shaker weight (kg): 11000
Vertical shaker dimension WxDxH(cm): 221x156x162
Power amplifier (kVA): 160
Power requirements (kVA): 230
Weight (kg): 2600
Rack dimension WxDxH(cm): 240x101x207
Cooling method: Water cooling
Internal cooling flow (L/min): 80
Internal cooling pressure (Mpa): 1
External cooling flow (L/min): 160
External cooling pressure (Mpa): 0.25~0.4
Internal cooling pump power (kw): 8
Cooling unit weight (kg): 300
Cooling unit dimension WxDxH (cm): 61x101x207
