Image Sensor: Global Shutter 1280 x 800
Aiming Element: Red Laser
Illumination: White LED (Risk Group Exempt)
Skew Angle: ±60°
Roll Angle: 0 - 360°
Optical Resolution: 1D 3 mil / 0.075 mm
Depth of Field (DOF PCS = 80%)
Symbology / X-DIM | Near | Far
13 mil UPC | 1.34 in / 3.4 cm | 22.5 in / 57.3 cm
5 mil Code 39 | 2.76 in / 7 cm | 11.85 in / 30.1 cm
10 mil Code 39 | 1.14 in / 2.9 cm | 20.3 in / 51.7 cm
20 mil Code 39 | 1.38 in / 3.5 cm | 31.5 in / 80 cm
15 mil Code 128 | 1.34 in / 3.4 cm | 25.6 in / 65 cm
10 mil Data Matrix | 2.84 in / 7.2 cm | 11.7 in / 29.7 cm
6.7 mil PDF417 | 3.3 in / 8.4 cm | 9.6 in / 24.4 cm
15 mil QR Code | 1.3 in / 3.3 cm | 15.35 in / 39 cm
Communication: Bluetooth LE V4.2 & Bluetooth 2.1 + EDR, Dual-Mode Class 1
Supported Host Interfaces: USB / RS232
Dimensions: 87.8 (L) x 71.6 (W) x 177.7 (H) mm
Weight: 213 g (without stand)
Trigger Switch Life: 10 million actuations
Barcodes Supported: 1D, 2D, OCR
Indicators: LED & Buzzer & Vibration
ESD Protection: Functional after 8 kV Contact and 15 kV Air Discharge
Mechanical Shock: 2.1 m drop on concrete (scanner only)
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -40°C to +70°C (-40°F to +158°F)
Ingress Protection: IP42
Accessories (Optional):
■ USB Cable (PN# 1550-905890G)
■ RS232 Cable (PN# 1550-905891G)
■ USB Type-C Cable (PN# 1550-905892G)
■ Single Slot Charging Cradle (PN# 5000-900064G)
■ Battery Pack (PN# 1400-900055G)
Certifications: CE, FCC, BSMI, VCCI, NCC, TELEC, BQB
Memory: 7.5 MB (up to 590,000 barcodes)
Key: Trigger Key
Wireless Coverage: 100 m (line of sight)
Interface Modes: Serial Port Profile & HID Profile
Stand Dimensions: 120.6 (L) x 88.7 (W) x 86.0 (H) mm
Battery Type: Rechargeable and Replaceable Battery Pack
Battery Capacity: 2850 mAh
Charging Time: < 6.5 hours
Operating Time: >25 hours (up to 60,000 scans at 1 scan/sec)
