Optical & Performance
Sensor: CMOS sensor with 1280 x 960 pixels, rolling shutter
Aiming Element: 610nm, Green LED
Illumination: 1 warm white LED
Skew Angle: ±60°
Pitch Angle Sensor: ±60°
Roll Angle: 0 - 360°
Optical Resolution: 5.0 mil (Code 39), 6.6 mil (PDF417)
Printing Contrast Scale: Minimum 20%
Depth of Field(DOF PCS=80%)
SYMBOLOGY / X-DIM TYPICAL RANGE* Near │ Far
5 mil Code 39 │ 2.4 in / 6.1 cm │ 9.5 in / 24.1 cm
5 mil Code 128 │ 2.8 in / 7.1 cm │ 9.0 in / 22.9 cm
6.67 mil PDF417 │ 2.4 in / 6.1 cm │ 8.0 in / 20.3 cm
10 mil Data Matrix │ 2.9 in / 7.4 cm │ 8.5 in / 21.6 cm
100% UPC │ 1.8 in / 4.6 cm │ 19.5 in / 49.5 cm
15 mil QR │ 1.2 in / 3.0 cm │ 11.5 in / 29.2 cm
20 mil QR Code │ 1.5 in / 3.8 cm │ 11.5 in / 29.2 cm
Communication
Radio: Corded
Host Interface supported: USB / RS232
Mechanical
Dimension: 87.8 L x 71.6 W x 177.7 H (mm)
Weight: 147g without cable
Trigger Switch Life: 10 million times
Symbologies
1D Barcodes: UPC/EAN/JAN, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5 (ITF), Discrete 2 of 5 (DTF), Codabar
(NW - 7), MSI, Chinese 2 of 5, Matrix 2 of 5, Inverse 1D, GS1 DataBar, Composite Codes
2D Barcodes: PDF417, MicroPDF417, Code 128, Data Matrix, GS1 Data Matrix, Data Matrix Inverse, Decode Data Matrix,
Maxicode 294, QR Code 293, GS1 QR Code, Micro QR Code, Linked QR Code, Aztec, Aztec Inverse, Han Xin
Code, Han Xin Inverse, Grid Matrix, Grid Matrix Inverse, Grid Matrix Mirror, Macro PDF
Electrical
Operation Voltage: DC 5V +/- 10%
Current Consumption
Operating: 235mA
Standby: 60mA
