Sensor: Laser engine
Scan Rate: 104 (± 12) scans/second (bi-directional)
Pitch Angle: ±40° from normal
Optical Resolution: 4 mil (0.1mm)
Depth of Field:
Symbology | Density | Near | Far
Code 128, 5 mils | 3.55 cm | 17.78 cm
Code 39, 5 mils | 3.05 cm | 26.67 cm
Code 39, 7.5 mils | 3.04 cm | 41.91 cm
Code 128, 10 mils | 3.05 cm | 40.46cm
UPC, 13 mils | 4.57 cm | 63.50 cm
Code 128, 15 mils | 5.08 cm | 66.04 cm
Code 39, 20 mils | 3.56 cm | 116.84 cm
Code 39, 55 mils | 8.64 cm | 177.80 cm
Code 39, 100 mils | 60.96 cm | 457.20 cm
Dimensions: 87.8 L x 71.6 W x 177.7 H (mm)
Weight: 147g without cable
Trigger Switch Life: 10 million times
Barcodes: 1D
Operating Voltage: 4 VDC to 5.5 VDC
Current Consumption: Operating Mode: <110mA Standby Mode: <20mA
Indicators: Direct decode indicator, good decode LED, beeper (tone/volume adjustable)
ESD Protection: Functions after 8K Contact and 15K Air
Mechanical Shock: 2.1M drop to concrete (scanner only)
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -40°C to +70°C (-40°F to +158°F)
Standard: IP42
Accessories (Optional): Standard hands-free stand (Optional)
Certifications: CE, FCC, BSMI, VCCI
