Sensor: CMOS sensor (640 x 480 pixels)
Aiming Element: White LED, Red LED (625nm)
Scan Rate: 30 frames per second
Pitch Angle: ± 60°
Roll Angle: 360°
Optical Resolution: ≥ 5 mil
Depth of Field: (Environment: 800 lux)
5 Mil Code 39: 45 ~ 145 mm
13 Mil UPC/EAN: 65 ~ 345 mm
6.67 Mil PDF417: 55 ~ 120 mm
15 Mil QR Code: 35 ~ 165 mm
10 Mil Data Matrix: 50 ~ 115 mm
Wireless Coverage: Up to 100M (Open space)
Supported Host Interface: USB VCP, USB HID
Dimensions: 27.6 x 46.2 x 26.8 mm
Weight: 14g (without cable)
Trigger Switch Life: 100,000
Barcodes: 1D, 2D
Operating Voltage: DC 5V±5%
Current Consumption: Working current: <135mA; Standby current: <15mA
ESD Protection: Functions after 4KV contact, 8KV air discharge
Mechanical Shock: 1.5M drop to concrete (scanner only)
Operating Temperature: -20 ~ 55˚C
Storage Temperature: -40 ~ 70˚C
Relative Humidity: 0% ~ 95%RH (Non-condensing)
Standard: IP42
Accessories (optional): Micro USB to USB Type-C Cable (PN#1550-905916G)
Certifications: FCC, CE
Scan Rate: 60 frames/second
