Display Screen: LCD
Rated value 0~40℃
Input voltage: 0~15V/ 0~150V
Input current: 0~3A/ 0~30A
Input power: 150W
Minimum of operating voltage: 1.4V±0.1V at 30A
CV (Constant Voltage) mode
Range: 0.1~15V/ 0.1~150V
Resolution: 0.1mV/ 1mV
Accuracy: ±（0.03%+0.05%FS)
CV (Constant Current) mode
Range: 0~3A/ 0~30A
Resolution: 0.01mA/ 0.1mA
Accuracy: ±（0.03+0.05%FS)
CR (Constant Resistance) mode
Range: 0.05Ω~10kΩ
Resolution: 16bit
Accuracy: (0.1+0.01R)%
CP (Constant Power) mode
Range: 150W
Resolution: 10mW
Accuracy: ±（0.1%+0.1%FS)
Dynamic mode:
T1&T2: 10μS~50S/Res:1μS
Accuracy: 1μS/1mS±100ppm
Rising/falling slope: 0.0006A/μS-3A/μS
Minimum of rising time: 10μs
Readback voltage:
Range: 0~15V/ 0~150V
Resolution: 0.01mV/ 0.1mV
Accuracy: ±（0.02%+0.03%FS)
Readback current:
Range: 0~3A/ 0~30A
Resolution: 0.01mA/ 0.1mA
Accuracy: ±（0.03%+0.05%FS)
Readback power
Range: 150W
Resolution: 10mW
Accuracy: ±（0.1%+0.1%FS)
Overpower protection: Delay protection when ≥152 W, Immediately protection when ≥165 W
Overcurrent protection: Delay protection when ≥30.3 A, Immediately protection when ≥33 A
Overvoltage protection: Delay protection when ≥152 V, Immediately protection when ≥165 V
Over-temperature protection: ≥85℃
Test mode: 15 test modes: CC, CV, CR, CP, dynamic, OVP, time, OCP, CR-LED, battery, automatic list, short circuit, load effect, combination, list
Resistance of input terminal: 300KΩ
Fuse specification: 0.5A(110V)/0.25A(220V)
Communication interface: RS232
Protocol: SCPI
Data acquisition software: √
Standard accessory: Power cord
Power requirement: 110V/220V
Frequency 50/60Hz
Size mm (Length*Width*Height): 372*215*88
Net Weight (kg): 3.73
