Bandwidth: 350MHz
Channels: 4
Sampling rate (analog): 2.5GSa/s (Single channel), 1.25GSa/s (Dual channels)
Sampling rate (digital): 1.25GSa/s
Max. memory depth: 70Mpts
Waveform capture rate: 200,000wfms/s
Time base scale (s/div): 1ns/div~40s/div (Real-time sampling rate, memory depth display )
Time base scale (digital): 1ns/div~40s/div (Step by 1-2-4 stall)
Input impedance: （± 1%@1MΩ， ±1.5%@50Ω） ||（18 pF± 3 pF）
Input impedance (digital): (101kΩ±1%) II (9pF±1pF)
Vertical scale (V/div): 1mV/div~10 V/div (1 MΩ)； 1mV/div~1V/div (50Ω)
DC gain accuracy: ≤±3%
Waveform record: 100,000 frames
Trigger types: 18
Mathematical operations: A+B, A-B, A×B, A/B, FFT, editable advanced and logical operations digital filtering
Auto measurements: 34
Number of measurements: Display 5 measurements at the same time
Measurement statistics: Average, Max, Min, standard deviation, number of measurements
Frequency counter: 7 bits
Standard interfaces: USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail), AWG(Only MSO3000E), UT-M12(Optional), VGA
Power: 100V~240V AC, 50Hz/60Hz
Display: 8 inch TFT LCD, WVGA (800x480)
Product net weight: 4.2kg
Product size (W×H×D): 370mm x 195mm x 125mm
