Output voltage: 0~30V(CH1/CH2);0~6V(CH3)； 5V（CH4）
Output current: 0~5A(CH1/CH2);0~3A(CH3)； 2A（CH4）
Output power: 328W
Load regulation: CV: ≤0.01%+2mV
CC: ≤0.01%+250μA
Line regulation: CV: ≤0.01%+2mV
CC: ≤0.01%+250μA
Resolution: Voltage: 10mV
Current: 1mA
Programming accuracy: Voltage: ±（0.3%+20mV）
Current: ±(0.2%+5mA)
Readback accuracy: Voltage: ±（0.1%+20mV）
Current: ±（0.15%+5mA)
Ripple and noise: Voltage: ＜350μVrms/2mVpp(5Hz~1MHz)
Current: ≤2mArms
Temperature coefficient: Voltage:0.01%+5mV;
Current: 0.01%+2mA
Parallel load regulation: ≤0.01%+2mV
Parallel line regulation: ≤0.01%+2mV
Series load regulation: ≤300mV
Series line regulation: ≤0.01%+3mV
Standard interfaces: USB Host
(5V/2A, charging port only),
USB Device, LAN, RS-232,Digital I/O
Power: AC 100V/120V/220V/230V±10%, 50Hz/60Hz
Display: 4.3 inch LCD
Product net weight: 10.2kg
Product size (W×H×D): 355mmx240mmx 168mm
