Detector Data
Type: Uncooled FPA
IR resolution: 1024 × 768
Pixel pitch: 17μm
Spectral range: 7.5~14μm
NETD/Sensitivity: 30mK
Lens Data
FOV: 28° x 21°
Minimum imaging distance: 1m
IFOV: 0.48mrad
Focus: Manual/Motor/Continuous autofocus/Laser assisted focusing
Image Performance
LCD: HD 5" color digital LCD, 1280 × 720
Viewnder: 0.5" color OLED display, supporting manual zoom, 1024×768
Visual camera: 13 megapixel CMOS, autofocus, LED ll light
Frequency: 50Hz/60Hz
Amplication: 1X~35X continuous
Palette: 12 palettes (including iron red, rainbow, black hot and white hot, etc.)
Contrast/brightness: Auto/Manual
Measurement
Temperature range: -20°C~+600°C(can be extended to 1200°C)
Measurement accuracy: 5°C~150°C, accuracy is ±1°C or ±1% of reading; for other temperature ranges, the accuracy is ±2°C or ±2% of reading, take the larger value
Measurement mode: Real-time 20 movable spots, 10 movable rectangular areas and 10 circular areas (max. /min. temp capture, avg. temp measure), 20 movable line temp measure, isothermal analysis, temp difference measure, temp alarm (sound, color)
Measurement correction: Auto/Manual
Emissivity correction: Adjustable from 0.01 to 1.0 or selected from list of materials
Background temperature correction: Auto (according to the input background temp)
Atmospheric transmissivity correction: Auto according to the input distance, relative humidity, ambient temp
Setting function: Date/time, temp unit °C/°F/K, language
Image Storage
Memory card: 64G
Storage method: Auto/manual store image in frame
Single frame infrared image format: JPEG, with 14-Bit measured data image
Single frame visible image format: JPEG or stored with single frame image
Text annotation: Support 30 preset text annotations (editable)
Voice annotation: 60s voice record, stored with per image via built-in microphone
Laser Indicator
Grade/Type: Class2, 1mW , 650nm Red
Laser Ranging: Measuring distance: 0.1m-50m
Interfaces
Power interface: Yes
SD card slot: Yes
Video output: HDMI
Audio output: Yes
USB interface: USB TypeC: Data transmission, radiometric video streaming
WIFI: Yes
Bluetooth: Yes
4G: Optinal
GPS: Yes
Compass: Yes
Tripod: 1/4″_20
Power System
Battery type: Lithium battery rechargeable
Battery operating time: 4h continuous room temperature
External power: DC: 5V
Charging system: Two-seater charger or in camera (AC adapter or 12V car charger)
Power saving: Yes
Enviroment Parameters
Operation temperature range: -20°C~+50°C
Storage temperature range: -40°C~+70°C
Humidity: ≤95% INon-condense
Vibration: 2G IEC60068-2-6
Shock: 25G IEC60068-2-29
Enclosulation: IP54 IEC60529
Physical Data
Size: 200mm × 110mm × 156mm
Weight: ≤1.6kg (with battery and standard lens)
Packing
Standard: Thermal imaging camera, 2 lithium batteries, battery charger, adapter, USB cable, SD card, video cable, card reader, USB ash drive, warranty card, certicate, calibration book, carrying case
Optional accessories: Laptop, SLR camera
