Capacity: 10T,20T,30T,50T
Temp. Range: Room temp. ~300℃
Temp. Controller: LED Indicator,press key set input, the value indicate output
Timer : LED display,time range 0.1S~99min~9.9hr
Heating type: Electrical Heating
Hot pressure plate: 300×300mm / 350x350mm / 500x500mm optional
Cold pressure plate: 300×300mm / 350x350mm / 500x500mm optional
Distance of pressure plate: 100mm
Pressure material: SKD chromium-molybdenum alloy
Pressure surface: Mirror chrome plated
Cooling temperature: Room temp. ~+5℃
Cooling type: Water cooling / Air cooling (optional)
Oil cylinder stroke: Max 200mm
Oil cylinder speed: 11mm/s
Pressure gauge: 0~350kg/sq.cm
Power: 10.6HP
Dimension (W×D×H): 1000×500×1500 mm
Power supply: 3 phase,AC380V,20A (or customize)
Weight: About 600kg
