Barrel parameters: Inner hole 9.55±0.025mm
Pistons parameters: Piston head: 9.475±0.015mm
Piston length: H=6.35±0.1mm
Paramters: Extrusion hole 1=2.095±0.005mm
Temperature parameter: With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade
Temperature range: 80degree centigrade~400degree centigrade
Temperature accuracy: ±0.2 degree centigrade
Display resolution: 0.1degree centigrade
Maximum comsuption: < 600W
Temperature recovery time: less 4 min.
Weight parameters are as follows:
Weight accuracy: ±0.5%
Basic configuration
A 0.325kg (including binder bar)
B 1.2 kg
C 2.16 kg
D 3.8 kg
E 5.0 kg
F 10 kg
G 12.5 kg
H 21.6 kg
Position detection
Loop distance from up and down: 30mm
Control precision: ± 0.1mm
Test flow control
Times of cutting the material: 0~10 times
Material cutting interval: 0~999s
Control flow reaches the set temperature without volatility
Barrel temperature time: 15 min.
Material be installed: 1 min.
Material sample temperature recovery time: 4 min.
When binder set: 1min
