Gain: 2 dBi, 3 dBi
VSWR: 2
Width: 60 mm
Height: 22.5 mm
Length: 82 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: RG174
Cable Length: 5 m
Polarization: RHCP
Mounting Style: Screw Mount
Number of Bands: 2 Band
Ground Plane Size: 15 cm
Maximum Frequency: 1.249 GHz, 1.606 GHz
Minimum Frequency: 1.197 GHz, 1.559 GHz
Termination Style: Connector
Antenna Connector Type: MCX Plug
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GNSS, GPS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
