- VOLTAGE/CURRENT LEVELS
Voltage Range: Range 1 - 0V to 50V
Range 2 - 0V to 80V
Current Range: 10mA to 50A
Power Range: Up to 750W
- OUTPUT SETTING
Operating Mode: Constant voltage, constant current or constant power with automatic cross-over dependent on output setting parameters CV, CC or CP mode indication in display
Voltage Setting: Resolution- 1mV for 50V range, (2mV for 80V range)
Current Setting: Resolution 10mA
Setting Accuracy: Voltage- 0.1% ± 2mV on 50V range, (0.1% ± 4mV on 80V range)
Current - 0.3% ± 20mA
- OUTPUT PERFORMANCE
Load regulation: <0.01% +5mV (CV mode) for any load change within the PowerFlex envelope,using remote sense.
Line regulation: <0.01% +5mV for a 10% line voltage change.
Ripple & Noise: (20MHz bandwidth): Typically <3mV rms, <20mV pk-pk.
Transient Response: To within 100mV of set level for a 5% to 95% load change.
Rear Terminals: <2ms
Front Terminals: <2.5ms
Sensing: Selectable local or remote sensing.
Output Protection: Output will withstand forward voltages of up to 90V
Reverse protection by diode clamp
Over Voltage protection (OVP): Settable 2V to 90V in 0.1V steps
Over Current protection (OCP): Settable 2A to 55A in 0.1A steps
- METER SPECIFICATIONS
Display Type: 4.3 inch (10.9 cm) backlit TFT LCD, 480x272 pixels total, 16 colours, resistive touch screen.
Meter Function: 5 digit voltage meter and 4 digit current meter. Display of limits values,memory contents etc. Wide range of alpha-numeric messages/menus.
Limits Display: Limits settings can be displayed simultaneously with measurements.
Meter Resolution: Voltage- 1mV (2mV on 80V range). Current- 10mA.
Meter Accuracy: Voltage: 0.1% of reading ± 2 digits.
Current: 0.3% of reading ± 2 digits.
- GENERAL SPECIFICATIONS
AC Input: 110V to 240V AC ±10%, 50/60Hz. Installation Category II.
Input Power: 1000VA Max.
Temperature: Operating: +5ºC to +40ºC, 20% to 80% RH, Storage: -40ºC to + 70ºC.
Safety: Complies with EN61010-1.
EMC: Complies with EN61326.
Size: 215 x 130 x 460mm (WxHxD) (3U High) Including terminals
Weight: <6.4kg (14lb)
