Width: 63.5 mm
Height: 27 mm
Length: 89 mm
Industry: Medical
Approvals: CE, CSA 60950-1, IEC 60601-1, UL 60950-1
Dimensions: 89 mm x 63.5 mm x 27 mm
Output Power: 60 W
Input Voltage: 90 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 4 A
Output Voltage-Channel 1: 15 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
