TT Electronics / Power Partners PAA25-14C AC-DC Power Modules 25W/24V AC/DC ENCAP/CHASSIS

Width: 53.9 mm

Height: 29 mm

Length: 96 mm

Industry: Industrial

Approvals: EN, IEC, TUV, UL

Dimensions: 96 mm x 53.9 mm x 29 mm

Output Power: 25 W

Input Voltage: 90 VAC to 305 VAC, 127 VDC to 430 VDC

Mounting Style: Chassis

Input Frequency: 47 Hz to 440 Hz

Load Regulation: Regulated

Isolation Voltage: 4 kVAC

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 1.042 A

Output Voltage-Channel 1: 24 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 40 C
