Width: 5.84 mm
Height: 13.97 mm
Length: 6.48 mm
Output Type: NPN Phototransistor
Unit Weight: 825.633 mg
Configuration: 1 Channel
Mounting Style: Through Hole
Isolation Voltage: 15000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 10 mA
Vf - Forward Voltage: 1.6 V
Vr - Reverse Voltage: 2 V
Current Transfer Ratio: 25 %
Pd - Power Dissipation: 100 mW
Maximum Collector Current: 44 mA
Current Transfer Ratio - Min: 25 %
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Maximum Collector Emitter Voltage: 30 V
Maximum Collector Emitter Saturation Voltage: 400 mV
