True Phantom Solutions ER-A01 Adult Ear For X-Ray CT, US, MRI

Size: 3 x 3 x 3 Inches

Weight: 1 Lbs (approx.)

Body Tissue

Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / Speckles

1410 ± 10 m/s / 1.01 g/cm³ / 1.3 ± 0.2 dB/cm / 35 Shore OO / NO

Cartilage

Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / Speckles

1800 ± 10 m/s / 1.03 g/cm³ / 25 ± 2 dB/cm / 65 Shore A / NO

Temporal Bone

Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / Speckles

3000 ± 30 m/s / 2.31 g/cm³ / 6.4 ± 0.3 dB/cm / N/A / N/A

Thermal Properties of Bone-Mimicking Tissue

Thermal conductivity / Volumetric specific heat capacity / Thermal diffusivity / Thermal resistivity / Specific heat / Speed of sound

0.776 W/m·K / 1.040 MJ/m³·K / 0.746 mm²/s / 1.289 m·K/W / 0.978 J/g·°C / 3070 m/s
