Technical data:
Idle speed 1. Speed level: 0 - 1.000
Impact frequency combined 1. Speed level: 0 - 5.000 min-1
Impact energy [Joule]: 2
Maximum drilling diameter:
Wood [mm]: 26
Metal [mm]: 13
Concrete / brickwork max. [mm]: 20
Electrical values:
Protection class: III
Sound values according to EN 60745:
Sound pressure level [dB(A)]: 82
Sound power level [dB]: 93
Uncertainty K [dB]: 3
Vibration information according to EN 60745:
Vibration emission value (ah) Hammer drilling in concrete (main handle) [m/s²]: 12.453
Uncertainty (K) Hammer drilling in concrete (main handle) [m/s²]: 1.5
Vibration emission value (ah) Hammer drilling in concrete (additional handle) [m/s²]: 10.716
Uncertainty (K) Hammer drilling in concrete (additional handle) [m/s²]: 1.5
Electrical values battery:
Battery nominal voltage [V]: 20
Battery capacity [Ah]: 4
Capacity indication: 3-stage
Battery type: Li-ion
Battery charging time [h]: 1.5
Charger:
Mains connection: 230 - 240 V, 50 Hz
Output voltage [V]: 21.5
Power input [W]: 94
Nominal current consumption [mA]: 3500
Connection plug: CEE 7/16
Cable length [m]: 1.5
Protection class: II
Dimensions:
Length (packaging excluded) [mm]: 305
Width (packaging excluded) [mm]: 110
Height (packaging excluded) [mm]: 195
Weight:
(packaging excluded) [kg]: 3
