Technical data:
Stroke rate at no load (combined): 0 - 2.700 min-1
Pendulum cutting stages: 0 – 3
Stroke [mm]: 20
Max. cutting depth (wood) [mm]: 80
Max. cutting depth (aluminium) [mm]: 12
Max. cutting depth (metal) [mm]: 5
Cutting angle: left/right: 0°/15°/30°/45°
Sound values according to EN 62841:
Sound pressure level [dB(A)]: 85
Sound power level [dB(A)]: 96
Uncertainty K [dB]: 5
Vibration information according to EN 62841:
Vibration emission value jigsaw blade wood (ah) [m/s²]: 5.86
Uncertainty jigsaw blade wood (K) [m/s²]: 1.5
Vibration emission value jigsaw blade metal (ah) [m/s²]: 6.15
Uncertainty jigsaw blade metal (K) [m/s²]: 1.5
Electrical values battery:
Battery nominal voltage [V]: 20
Battery capacity [Ah]: 2
Capacity indication: 3-stage
Battery type: Li-ion
Battery charging time [h]: 1
Charger:
Mains connection: 230 - 240 V, 50 Hz
Output voltage [V]: 21.5
Power input [W]: 65
Nominal current consumption [mA]: 2400
Connection plug: CEE 7/16
Cable length [m]: 1.5
Protection class: II
Dimensions:
Length (packaging excluded) [mm]: 250
Width (packaging excluded) [mm]: 75
Height (packaging excluded) [mm]: 200
Weight:
(packaging excluded) [kg]: 2
