Technical data:
Idle speed: 3.800 min-1
Max. idle speed [min-1]: 3800
Cutting depth range at 45 °: max. 36 mm
Cutting depth range at 0 °: max. 48 mm
Sound values according to EN 62841:
Sound pressure level LpA [dB(A)]: 89
Sound power level LwA [dB(A)]: 100
Uncertainty (K) Kpa / Kwa [dB]: 3
Vibration information according to EN 62841:
Vibration emission value (ah) Main handle (sawing wood) [m/s²]: 1.879
Uncertainty (K) Main handle (sawing wood) [m/s²]: 1.5
Vibration emission value (ah) Front handle (sawing wood) [m/s²]: 2.213
Uncertainty (K) Front handle (sawing wood) [m/s²]: 1.5
Saw blade data:
Idle speed saw blade [min-1]: 9000
Saw blade diameter [mm]: 150
Bore diameter [mm]: 16
Blade thickness [mm]: 0.9
Teeth thickness [mm]: 1.6
Electrical values battery:
Battery nominal voltage [V]: 20
Battery capacity [Ah]: 2
Capacity indication: 3-stage
Battery type: Li-ion
Battery charging time [h]: 1
Charger:
Mains connection: 230 - 240 V, 50 Hz
Output voltage [V]: 21.5
Power input [W]: 65
Nominal current consumption [mA]: 2400
Connection plug: CEE 7/16
Cable length [m]: 1.5
Protection class: II
Dimensions:
Length (packaging excluded) [mm]: 190
Width (packaging excluded) [mm]: 352
Height (packaging excluded) [mm]: 238
Weight:
(packaging excluded) [kg]: 2.6
