Trotec BD1L Laser Spirit Level (0.2 - 20 m; +/-3)

Distance measurement:

Min. measuring range [m]: 0.2

Max. measuring range [m]: 20

Max. typical range: 10 m

Resolution: 1 mm

Typical measuring tolerance: +/-3

Wurfweite Laser-Anreißlinie [m]: 10

Laser:

class: 2

Laserfarbe: rot

output < [mW]: 1

Wavelength [nm]: 670 nm

Display:

LCD (schwarz/weiß) 1,3":

Device control:

Push buttons: ✓

Housing design:

Plastics: ✓

Aluminium: ✓

Power supply:

Internal (battery): 3,7V Li-ion, 300 mAh

Ambient conditions:

Operation - min. temperature [°C]: -10

Operation - max. temperature [°C]: 50

Storage - min. temperature [°C]: -20

Storage - max. temperature [°C]: 60

Dimensions:

Width (packaging excluded) [mm]: 229

Height (packaging excluded) [mm]: 48

Depth (packaging excluded) [mm]: 19

Weight: (packaging excluded) [kg]: 0.217
