Connector Interface: 2X RJ45 (PSE & PD Test Jacks)
Voltage Range: Standard PoE: 36 to 60V; Non-Standard: 11 to 60V
Max Current (based on 50V): 990mA/50W per mode; Total 2A/100W
Function Selection Mode:
T Mode: for detecting PSE status
N Mode: for determining non-standard PoE + inline testing
I Mode: for testing & monitoring real-time power status
Display:
4 LEDs indicate IEEE802.3af or 802.3at/bt standard
Dual 7-digit LEDs indicate power source either end (A) Span (1/2, 3/6) or Mid (B) span (4/5, 7/8) or both for bt
2 Yellow LEDs indicate reversed polarity for power type
Display alternates between Voltage, Current and Power
Step Button: For selecting specific data to display
Power: Uses system power when connected to a device
Dimensions/Weight: 3.9 x 1.4 x 1 ” (99 x 36 x 26mm)/1.6oz (45.4g)
