Line Voltage: 200/230V
Output Voltage Range:
0 to ±125 V DC or peak AC
0 to -250 V DC or peak AC
0 to +250 V DC or peak AC
Output Current Range: ±40 mA DC; ±80 mA peak AC, for less than 1 ms
Input Voltage Range: 0 to ±10 V DC or peak AC
Input Impedance: 10 kΩ, nominal
DC Voltage Gain: 50 V/V
DC Voltage Gain Accuracy: Better than 0.1% of full scale
Offset Voltage: Less than 500 mV
Output Noise: Less than 20 mV rms*
Slew Rate (10% to 90%): Greater than 100 V/µs
Large Signal Bandwidth : DC to greater 150 kHz (5%distortion)
Dimensions: 433.8 mm H x 108 mm W 381 mm D (17” H x 4.25” W x 15” D)
Weight: 4.3 Kg
