Width: 95 mm (3.74 in)
Height: 38 mm (1.496 in)
Length: 159 mm (6.26 in)
Industry: Industrial
Efficiency: 79 %
Unit Weight: 265.356 g
Output Power: 80 W
Input Voltage: 88 VAC to 264 VAC, 125 VDC to 375 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 3 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 8 A
Output Current-Channel 2: 4 A
Output Current-Channel 3: 1 A
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 12 VDC
Output Voltage-Channel 3: - 12 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
