TRACO Power TRV 2-2410M Isolated 19.2-28.8Vin 3.3Vout 600mA 2W Encapsulated SIP-9 Medical, Regulated

Width: 9.9 mm (0.39 in)

Height: 12.5 mm (0.492 in)

Length: 19.6 mm (0.772 in)

Industry: Medical, Industrial

Dimensions: 9.9 mm x 19.6 mm x 12.5 mm

Unit Weight: 4.800 g

Output Power: 2 W

Input Voltage: 19.2 V to 28.8 V

Mounting Style: Through Hole

Isolation Voltage: 5 kV

Number of Outputs: 1 Output

Input Voltage - Max: 28.8 V

Input Voltage - Min: 19.2 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 600 mA

Output Voltage-Channel 1: 3.3 V

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
