TRACO Power TMV 1205 DEN Isolated

Width: 7.5 mm (0.295 in)

Height: 12.5 mm (0.492 in)

Length: 22 mm (0.866 in)

Industry: Industrial

Unit Weight: 4 g

Output Power: 1 W

Input Voltage: 10.8 V to 13.2 V

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 13.2 V

Input Voltage - Min: 10.8 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 200 mA

Output Voltage-Channel 1: 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 25 C
