Width: 25.4 mm
Height: 15.74 mm
Length: 38.1 mm
Industry: Industrial
Approvals: IEC/EN 60335-1, IEC/EN/UL 60950-1, IEC/EN/UL 62368-1
Compliance: IEC/EN 60335-1, IEC/EN/UL 60950-1, IEC/EN/UL 62368-1
Unit Weight: 29 g
Output Power: 8.6 W
Input Voltage: 85 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 2.6 A
Output Voltage-Channel 1: 3.3 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 25 C
