TRACO Power TMM 24215C Switching Supplies 24W AC/DC Power Supply in a Chassis Mount Plastic Case

Width: 54 mm (2.126 in)

Height: 19.5 mm (0.768 in)

Length: 74 mm (2.913 in)

Industry: Medical, Industrial

Approvals: EN60950-1, EN60601-1, UL 508

Compliance: EN 60950-1 , EN 60601-1 , UL 508

Efficiency: 84 %

Unit Weight: 147 g

Output Power: 24 W

Input Voltage: 85 VAC to 264 VAC, 120 VDC to 370 VDC

Mounting Style: Through Hole

Input Frequency: 47 Hz to 440 Hz

Load Regulation: Regulated

Isolation Voltage: 4 kVAC

Number of Outputs: 2 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 800 mA

Output Current-Channel 2: 800 mA

Output Voltage-Channel 1: 15 VDC

Output Voltage-Channel 2: - 15 VDC
