TRACO Power TEP 40-3618UIR Isolated 9-75Vin 48V 830mA 40W Qtr brick Iso

Width: 36.8 mm (1.449 in)

Height: 12.7 mm (0.5 in)

Length: 57.9 mm (2.28 in)

Industry: Industrial

Dimensions: 57.9 mm x 36.8 mm x 12.7 mm

Application: Railway

Unit Weight: 64 g

Output Power: 40 W

Input Voltage: 9 V to 75 V

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 75 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 36 V

Output Current-Channel 1: 830 mA

Output Voltage-Channel 1: 48 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
