TRACO Power TEN 40-3613UIR Isolated 40W 9-75Vin 15Vout 2670mA 2x1 housing

Width: 40.6 mm (1.598 in)

Height: 25.4 mm (1 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Dimensions: 50.8 mm x 40.6 mm x 25.4 mm

Application: Industrial

Unit Weight: 34.500 g

Output Power: 40 W

Input Voltage: 9 VDC to 75 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 75 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 36 V

Output Current-Channel 1: 2.67 A

Output Voltage-Channel 1: 15 V

Maximum Operating Temperature: + 90 C

Minimum Operating Temperature: - 40 C
